Garrett GTW3884R (450-950 HP)

Garrett GTW3884R (450-950 HP)

Horsepower:
450 - 950
Displacement:
2.0L - 6.0L

Super Core Reference Data Compressor Turbine
Super Core  CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
Journal Bearing 715582-0008 62mm 84mm 54 0.70 74mm 65mm 76
Journal Bearing 715582-0009 64mm 84mm 58 0.70 74mm 65mm 76
Journal Bearing 715582-0010 67mm 84mm 64 0.70 74mm 65mm 76
Ball Bearing 757197-0012 62mm 84mm 54 0.70 74mm 65mm 76
Ball Bearing 757197-0013 64mm 84mm 58 0.70 74mm 65mm 76
Ball Bearing 757197-0014 67mm 84mm 64 0.70 74mm 65mm 76

Features:
  • Ported shroud design for surge resistance.
  • Available in both journal bearing and ball bearing options.
  • Forged fully-machined billet compressor wheel.
  • Inconel super-alloy turbine wheel.
  • Lightweight aluminum backplate.

Garrett® GTW Series Turbochargers were designed to provide budget-minded enthusiasts with a high-performing mid frame product offering available in ball bearing and journal bearing options.

The fully-machined billet aluminum compressor wheels provide optimal horsepower range and boost response. Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A lightweight aluminum backplate comes standard on all GTW turbochargers and reduces overall weight.

The water cooled CHRA keeps housing temperatures to a minimum. The GTW3476 and GTW3884 turbine wheels are constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. The GTW is a cost effective option for enthusiasts looking to turbocharge their vehicles.

Select Journal or Ball Bearing
Select Compressor Inducer Wheel Size
Select Turbine Housing Option (A/R, Inlet, Outlet)
From $387.36

Original: $1,106.73

-65%
Garrett GTW3884R (450-950 HP)—

$1,106.73

$387.36
Product image 1
Product image 2
Product image 3
Product image 4

Description

Horsepower:
450 - 950
Displacement:
2.0L - 6.0L

Super Core Reference Data Compressor Turbine
Super Core  CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
Journal Bearing 715582-0008 62mm 84mm 54 0.70 74mm 65mm 76
Journal Bearing 715582-0009 64mm 84mm 58 0.70 74mm 65mm 76
Journal Bearing 715582-0010 67mm 84mm 64 0.70 74mm 65mm 76
Ball Bearing 757197-0012 62mm 84mm 54 0.70 74mm 65mm 76
Ball Bearing 757197-0013 64mm 84mm 58 0.70 74mm 65mm 76
Ball Bearing 757197-0014 67mm 84mm 64 0.70 74mm 65mm 76

Features:
  • Ported shroud design for surge resistance.
  • Available in both journal bearing and ball bearing options.
  • Forged fully-machined billet compressor wheel.
  • Inconel super-alloy turbine wheel.
  • Lightweight aluminum backplate.

Garrett® GTW Series Turbochargers were designed to provide budget-minded enthusiasts with a high-performing mid frame product offering available in ball bearing and journal bearing options.

The fully-machined billet aluminum compressor wheels provide optimal horsepower range and boost response. Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A lightweight aluminum backplate comes standard on all GTW turbochargers and reduces overall weight.

The water cooled CHRA keeps housing temperatures to a minimum. The GTW3476 and GTW3884 turbine wheels are constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. The GTW is a cost effective option for enthusiasts looking to turbocharge their vehicles.
