Garrett GT3071R (280-480 HP)

Garrett GT3071R (280-480 HP)

Horsepower:
280 - 480
Displacement:
2.5L - 3.5L
Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836028-5001S 836000-0002 53mm 71mm 56 0.50 60mm 55mm 84
836028-5002S 836000-0002 53mm 71mm 56 0.50 60mm 55mm 84
836028-5004S 836000-0001 53mm 71mm 56 0.50 60mm 55mm 84
836028-5005S 836000-0001 53mm 71mm 56 0.50 60mm 55mm 84
Features:
  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Non wastegated turbine housings available.
  • Ball bearing configuration with water cooled CHRA.
  • V-band turbine housing options.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
Select Compressor Housing (Inlet and Outlet)
Select Turbine Housing Option (A/R, Inlet, Outlet)
From $332.45

Original: $949.87

-65%
Garrett GT3071R (280-480 HP)—

$949.87

$332.45
Product image 1
Product image 2
Product image 3
Product image 4

Description

Horsepower:
280 - 480
Displacement:
2.5L - 3.5L
Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836028-5001S 836000-0002 53mm 71mm 56 0.50 60mm 55mm 84
836028-5002S 836000-0002 53mm 71mm 56 0.50 60mm 55mm 84
836028-5004S 836000-0001 53mm 71mm 56 0.50 60mm 55mm 84
836028-5005S 836000-0001 53mm 71mm 56 0.50 60mm 55mm 84
Features:
  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Non wastegated turbine housings available.
  • Ball bearing configuration with water cooled CHRA.
  • V-band turbine housing options.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
