Garrett GT2554R (170-270 HP)

1.4L - 2.2L

Turbo Reference Data		Compressor				Turbine
Turbo PN	CHRA	Inducer	Exducer	Trim	A/R	Inducer	Exducer	Trim	A/R
836023-5001S	835995-0001	42mm	54mm	60	0.80	53mm	42mm	62	0.64



Features:

• Original GT series aerodynamics.
• Internally wastegated turbine housing.
• Sold as a complete turbo (includes turbine kit & actuator).
• Smallest ball bearing configuration available.
• Water cooled CHRA.

Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
